Firmness of soft fruits

Tomato, cherry, blueberry, strawberry,

apricot, blackberry, cranberry, plum,

olive...

The Agrosta 100 Field is the historical Durofel,

upgraded 8 times since 1987 (First design with

the CTIFL)

It is a firmness tester for soft fruits like

tomatoes, blueberries or cherries. It is used all

over the world since many years, and has proven

its efficiency in classifying the fruits according to

maturity.

The new version calculates statistics, comes with

a speech function, a touchscreen and a microSD

which stores the data under Excel compatible

format

The Agrosta 100 Field comes with Bluetooth Low

Energy, and can communicate with a smartphone

through a free APP

The APP uses the Barcode scanner and the GPS

module of the smartphone

This firmness tester for soft fruits using the

Durofel standard is used daily by all the major

companies of the tomato seeds sector in the

world, The 100 Field is a reference as well in the

blueberry and cherry sectors

Many publications are available on the web

concerning the Durofel principle, mainly for

tomato, cherry, blueberry and strawberry

Color Touchscreen :

2.4” touchscreen, you can use the touch buttons

to pilot the machine, name and consult the

batches and switch ON or OFF the sound

Speech Function :

The Agrosta 100 Field tells you all results after

measurement - It is extremely comfortable for

the user that does not need to watch the screen.

The average is told once the batch is finished

MicroSD slot :

All measurements are stored on the MicroSD once

you finish a batch. You can use the keypad

proposed on the color touchscreen in order to

give a name to the current file

The file is a csv (Excel compatible) - Here is how

it looks like on Excel :

Bluetooth Low Energy :

The Agrosta 100 Field communicates with any

Android device via BLE. The APP is free, a QR

code is provided on the manual, and you can

download it and install it on a phone or tablet

The APP uses optionally the GPS positioning and

Barcode scanner of your phone or tablet - so you

will have this data inside the file generated

The APP stores your data on a csv file as well

You can see on the left how the APP looks like

Statistics calculation :

The statistics are extremely important when

evaluating the quality of a batch of fruits

Especially the standard deviation, which gives an

excellent picture of the firmness homogeneity

When using a device like the Agrosta 100 Field,

you will not deliver on the market a blueberry

bucket with in the same bucket very soft and

very hard berries (For example)

It is one of the most important quality factor

Sensor, calibration, maintenance :

The sensor structure is made with ceramic micro-

particles, which ensures an extreme rigidity and

temperature stability for unparalleled precision

The sensor comes with a double check system,

which means that once you obtain a value of

100% on a hard flat surface, you have the

guarantee that the device is fully calibrated. the

calibration is very stable, and till now, the

versions 7 and 8 devices never came back for

calibration.

The maintenance is very easy, just remove the

plastic cover and clean any fruit juice on the tip

and cover with soap and water

Fruit juice protection :

None of our competitors manages this point,

which is one of the most important

One day or another, a fruit will crack and pollute

the sensor head..

Our instruments come with a set of 20

protections for the sensor head - More

protections can be purchased on the shop page of

our website
